Description Lifting points pivots 360 degrees. Suspension ring pivots 180 degrees. Optimal WLL with captive but exchangeable ICE-BOLT made out of patented steel with special corrosion protection Corrud-DT. Non-hazardous deep temperature usage down to -60 degrees; higher toughness and therefore higher bending strength as well as less wear occurance. Original ICE-bolt is available as a spare part. Clear marking at the bolt head: RUD, ICE, thread size, batchno., class off strength. Clamping Spring works as a noise reduction and holds the suspension ring in the requested position; therefore, simple hinge of lifting mean possible respectively flat design if turned down. Clear marking of the minimum WLL for all loading directions Available As: Standard Metric Thread (DIN EN 13) Variable bolt lengths available for tapped or through holes. Tested and certified by DGUV Testing specifications: GS-HM-36:2021-09 Certificate No.: HM 220053 Quick and easy installation with just one bolt connection. Assembly with flat / ring wrench or allen key possible. Hand tightening with appropriate wrench is sufficient for a singular lift. Please observe torque instructions when lifting point is permanently installed resp. at constant swivelling operations and tilting/ turning actions.
